161
• German electrostatic dry-powder enamel inner tank, corrosion-resistant and highly durable, with a ABS outer casing
• 360° high-pressure integrated PU foaming for superior heat insulation
• SUS316L heating element with high thermal efficiency
• Mechanical control with pointer or digital display; easy to operate
• Multiple safety protections: anti-leakage, over temperature protection, dry-heating prevention
Product Technical Specifications
Complete technical specifications and dimensional data for all product models
Electrical & Performance Specifications
| Parameter | Specification |
|---|---|
| Rated Voltage | 220V~ |
| Rated Frequency | 50HZ |
| Rated Power | 2100W |
| Rated Pressure | 0.7MPa (±0.05) |
| Waterproof Rating | IPX4 |
| Temperature Setting Range | 35 ~ 75℃ |
Capacity & Dimensional Specifications
| Capacity (L) | Product Dimensions (mm) Length × Diameter | Net Weight (kg) | Packaging Dimensions (mm) L × W × H | Gross Weight (kg) | Volume (m³) |
|---|---|---|---|---|---|
| 30 | 565 × 340φ | 10.5 | 670 × 385 × 400 | 12 | 0.10 |
| 40 | 685 × 340φ | 12.3 | 800 × 385 × 400 | 13.8 | 0.12 |
| 50 | 605 × 410φ | 13.4 | 720 × 455 × 470 | 15.1 | 0.15 |
| 60 | 695 × 410φ | 16 | 810 × 455 × 470 | 18 | 0.17 |
| 80 | 865 × 410φ | 19 | 960 × 455 × 470 | 21 | 0.21 |
Notes:
- All specifications are measured under standard testing conditions and may vary slightly in actual use due to environmental factors.
- Product dimensions are approximate and subject to change without notice.
- IPX4 waterproof rating indicates protection against water splashes from any direction.
- All models feature the same electrical specifications and differ only in capacity and dimensions.
